KUNGFLEX SQ300 Air tubing

General purpose thermoplastic air water pipes
Constant pressure: 20.7bar/300psi
Colors are available: black, red, blue, yellow, gray

产品详细PDF下载

Filter by:

The hose is nominal ID DN

Inner Diameter (inch)

Order number	The hose is nominal ID DN	Inner Diameter (inch)	Outer Diameter(mm)	Maximum working pressure (bar)	Maximum working pressure（psi）	Burst pressure bar	Minimum bending radius (mm)	Weight (kg/m)

● Temperature: -40°F to 200°F (-40°C to 93°C) uninterrupted service.
● Structure: Inner rubber layer P-class EPDM rubber, black.
● Reinforcement layer: high-strength synthetic fiber.
● Outer rubber layer: D3 special composite elastomer. Class P EPDM rubber. All sizes less than 1/2" are needled.
● Design coefficient: 3:1
● Standards:
Inner adhesive: Meets ARPM (Class C) low oil resistance standard
Outer adhesive: Meets ARPM (Class C) low oil resistance standard.
● Recommended Use: Air and water applications that require maximum flexibility in any industry, including dispenser pneumatic drives and cooling, mining, construction, agriculture, vehicle repair, data center and factory cooling water applications.
Excellent heat and ozone resistance. Suitable for light agricultural spraying, such as brine solutions for herbicides.
